NOT
MEASUREMENT
SENSITIVE
MIL-PRF-28000B
30 SEPTEMBER 1999
SUPERSEDING
MIL-PRF-28000A
10 FEBRUARY 1992
PERFORMANCE SPECIFICATION
DIGITAL REPRESENTATION FOR COMMUNICATION OF PRODUCT DATA:
IGES APPLICATION SUBSETS AND IGES APPLICATION PROTOCOLS
This specification is approved for use by all Departments and Agencies of the Department of Defense.
1. SCOPE
1.1 Scope. This specification identifies the requirements to be met when product definition data is
delivered in the digital format of the Initial Graphics Exchange Specification (IGES, in accordance with
the American National Standard (ANS) / United States Product Data Association (US PRO) standard.
Discrete subsets and application protocols of the IGES entities are identified by class according to the
application for which the digital data was prepared.
Beneficial comments (recommendations, additions, deletions) and any pertinent data which may be
used in improving this document should be addressed to: ATTN CALS Digital Standards Office,
DISA Center for Information Technology Standards, Code JIEO/JEBEB, 10701 Parkridge Blvd,
Reston VA 20191-4357, by using the self-addressed Standardization Document Improvement
Proposal (DD Form 1426) appearing at the end of this document or by letter.
AMSC N/A
AREA IPSC
DISTRIBUTION STATEMENT A. Approved for public release; distribution is unlimited.
1
